Chapter 2 Operations

55

[3] Encoder pulse count per rotation (output channel parameter No. 5)

This parameter sets the number of pulses per encoder rotation of the control target axis (unit:

pulse). Make the setting according to the specification of the control target axis.

[4] Screw lead (output channel parameter No. 6)

This parameter sets the ball screw lead length of the control target axis (unit: 0.001 mm). Make

the setting according to the specification of the control target axis.

[5] Software limit +/software limit - (output channel parameters No. 7 and 8)

These parameters set the software limit + and -, respectively, of the control target axis (unit:

0.001 mm). Make the setting according to the specification of the control target axis.

[6] Software limit margin (output channel parameter No. 9)

This parameter sets the maximum following error at which instance an error is detected while

synchronous movement is being performed (unit: 0.001 mm). The software limit error occurs in

the following cases.

x

Command position > [software limit +] + [software limit margin]

x

Command position < [software limit -] - [software limit margin]

Caution: Set these parameters taking the distance from the software limit to the mechanical end of

the control target axis into consideration. If the setting value is too large, there is a risk

that an axis collides with the mechanical end.
