x MAP Technology Using Luminex 100 IS 2.2 Software
PN 89-00002-00-069 Rev. A 6 - 45
Acquisition Detail tab Main features:
• New Advanced Batch
• View Batch Data
• Replay
• Histogram
• Dot Plot
This section provides an overview and basic descriptions of the
Acquisition Detail. Refer to the Luminex 100 IS Developer Guide for
xMAP Technology for detailed operation. Figure 47 displays the
Acquisition Details tab and identifies the major components.
Figure 47. Acquisition Detail Tab
7
6 5
3 4 1 2
1. IS Toolbar 5. Status bar
2. Batch name and description 6. Histogram
3. Batch data area and buttons 7. Dot Plot
4. Acquisition detail toolbar
