Luminex 100 IS Version 2.2 - Manual (Page 123)

x MAP Technology Using Luminex 100 IS 2.2 Software
PN 89-00002-00-069 Rev. A 6 - 69
‹ To edit a patient list:
1. From the File menu, select Edit Patient List. The Open Batch
dialog box appears.
2. Select the desired unprocessed batch containing the patient list
that you want to edit and click Select. The Edit Patient List
dialog box appears similar to Figure 65.
3. Edit the desired patient and associated dilution factor
information. Click Finish to accept your edits and close the
dialog box.
Figure 65. Edit Patient List Dialog Box
Change Start
Acquiring Data
Location
While creating a batch, you can define where to begin acquiring
samples; that is, in a location other than the first available empty
well. Once you open a batch for processing, you cannot change the
location where data acquisition begins.
‹ To establish where to begin acquiring data on the microtiter plate
during batch creation:
1. From the microtiter plate representation on the Batch Setup
dialog box, click the first well for sample acquisition.
2. Drag the highlighted well to the desired start location on the
microtiter plate. The display updates to show the wells new
location. Empty wells in front of the new starting well now
appear red.
When you process this batch, the system starts acquiring data in
the well indicated.
