Luminex 100 IS Version 2.2 - Manual (Page 183)

x MAP Technology Maintenance and Cleaning
PN 89-00002-00-069 Rev. A 7 - 7
Figure 125. Removing the Screen
3. Replace the filter and replace the screen. See Figure 126.
Figure 126. Removing and Replacing the Filter
4. Plug in and turn on Luminex XYP instrument power.
