Luminex 100 IS Version 2.2 - Manual (Page 163)

x MAP Technology Using Luminex 100 IS 2.2 Software
PN 89-00002-00-069 Rev. A 6 - 109
Maintenance Report, Calibration Trend Report, and System
Control Trend Report a dialog box related to the specific report
appears.
Figure 99. Batch Selection Dialog Box
3. Enter the information (in this example, a patient report) and click
Next. Another information dialog box appears. Enter specific
information for the type of report the system is compiling.
Figure 100 shows a Patient Selection example.
Figure 100. Patient Selection Dialog Box
4. Select the desired entry or click the double arrow (>>) to select
all the entries.
5. Click Finish. A report print preview appears using the
information you entered. See Figure 101. You may have more
than one dialog box in which to enter information.
Note: The system information
may vary depending on the type
of report that you select.
