x MAP Technology Using Luminex 100 IS 2.2 Software
PN 89-00002-00-069 Rev. A 6 - 23
Figure 33. Command List Section on the Run Batch Tab
Figure 34 shows an example of a failed command in the command
list on the Run Batch tab.
Figure 34. Command Failure Notation In Command List
If an error occurs during the batch, it is recorded in the Message Log.
See “Error Messages” on page 6-44 for details. Double-click the
failure row for additional information if it is highlighted in yellow.
Right-click the highlighted row to copy data to the clipboard or to
clear the batch from the screen. Click the Print Batch Worklist
option, above the upper-right corner, to print the list of commands
from the command list. This applies to the current loaded batch.
