Luminex 100 IS User Manual Version 2.2 x MAP Technology
6 - 104 PN 89-00002-00-069 Rev. A
• Color Tab—Use the Color tab to define the various color
parameters on the analysis graph. See Figure 95.
Desk Foreground: this is the color that is used when placing
text onto the Desk Background. It includes the main title, sub
title, subset/point labels, grid numbers.
Desk Background: this is the color that surrounds the
bounding rectangle of the graph's grid. That is, the color of the
border that appears behind the text labeling.
Shadow Color: the rectangles that make up the graph's grid
and table and bounded at the bottom/right edges with shadows.
To remove the shadows, choose the same color as the Desk
Background.
Graph Foreground: this is the color used for the bounding
rectangles of the grid, the grid-lines of the graph, and lines that
are used to bound some of the plotting methods (like the
bounding line around bars of the Bar Plotting Method).
Graph Background: this is the color that is used as the
background color of the graph's grid.
Table Background: This is the color used in filling the table's
rectangle. Currently, this feature is not used.
Table Foreground: This is the color used in bounding the
table's rectangle, and for the text inside the table. Currently,
this feature is not used.
Figure 95. Customization Dialog Box—Color Tab
• Style Tab—use the Style tab for control of subset color,
subset line type, and subset point type. See Figure 96. To edit
the Style tab:
