x MAP Technology Using Luminex 100 IS 2.2 Software
PN 89-00002-00-069 Rev. A 6 - 19
Run Batch Tab
The Run Batch tab contains a command list displaying batch
commands and their status, a microtiter plate image, plate command
buttons, and XYP command buttons and settings. See Figure 30.
Figure 30. Run Batch Tab
Run Batch Tab Buttons
There are six buttons on the Run Batch Tab. These commands are
also available on the Acquisition Detail Toolbar.
Start Plate Select to initiate data acquisition on new advanced and batches set up
using system templates.
Cancel Command Select to cancel the process for the last command initiated in the
system.
Cancel All Select to cancel all the commands in process. It essentially performs
an abort operation.
Eject (Retract) If retracted, select to direct the Luminex XYP to eject the microtiter
plate. If ejected, select to direct the Luminex XYP to retract the
microtiter plate.
Pause Select to pause or interrupt the command that the system is currently
processing.
Resume Select to resume or continue the process that was paused.
2
3
5
1
6
4
1. Microtiter Plate Image 4. Progress (when running)
2. XYP Reservoir 5. Print Button
3. Pressure Range 6. Command List
