Luminex 100 IS Version 2.2 - Manual (Page 37)

x MAP Technology The System
PN 89-00002-00-069 Rev. A 3 - 11
Access Doors Two access doors are on the face of the Luminex 100 analyzer. The
center door gives you access to the syringe. The left door provides
service panel access. See Figure 4.
1. Left door, access to service panel
2. Center door, access to syringe
Figure 4. Luminex 100 Analyzer Access Doors
Air Intake Filter A replaceable air filter cleans the air used to pressurize sheath fluid.
This filter is enclosed behind an access door located on the back of
the Luminex 100 analyzer. See Figure 5.
Figure 5. Air Intake Filter
2 1
