System Overview ReFlex Power™
1-6 M380056-01 Rev J
1.3 SPECIFICATIONS
The flexible and reconfigurable characteristics of the ReFlex Power TM
system allow any combination of module(s) to be plugged into a
Mainframe, and in any of the slot locations; i.e., the various power asset
types (high-power/low-power DC, AC, and/or loads), as well as the
Controller, can be combined and changed as needed. With twelve slots in
the Mainframe, multiple modules of single-width, double-width and/or
triple-width can be plugged in. If the combined width of the desired assets
exceeds the inner dimensions of the Mainframe (twelve slots at single-
width each), the assets can be extended through interconnection of
additional Mainframes. Table 1-1 provides an overview of each type of
module that can be utilized in the system.
1.3.1
P
RODUCT
M
ATRIX
- O
VERVIEW
Table 1-1. Module Complement
Model Type
Voltage
Rating
Current
Rating
Power
Rating
Module
Width
RFP-D1016-021-xxxx
Low-power DC
module
0-16 V 0-20.6 A 330 W Single (1.4”)
RFP-D1065-5A1-xxxx
Low-power DC
module
0-65 V 0-5.1 A 332 W Single (1.4”)
RFP-D2033-030-xxxx
High-power
DC module
0-33 V 0-30 A 990 W Double (2.8”)
RFP-D2050-020-xxxx
High-power
DC module
0-50 V 0-20 A 1000W Double (2.8”)
RFP-D2050-025-xxxx
High-power
DC module
0-50 V 0-25 A 1250W Double (2.8”)
RFP-D2120-8A3-xxxx
High-power
DC module
0-120 V 0-8.3 A 996W Double (2.8”)
RFP-D2450-2A3-xxxx
High-power
DC module
0-450 V 0-2.3 A 1,035 W Double (2.8”)
RFP-A30XK-875-xxxx
AC power
module 0-140/
0-280V 3.5A/
7A
875W Triple (4.2”)
RFP-L3500-750-xxxx
High-power
active load
500V 30A 750W Triple (4.2”)
RFP-L3500-375-xxxx
Low-power
active load
500V 15A 375W Triple (4.2”)
RFP-F1000-001-xxxx
Fixed-power
DC module 5/-5V
15/-15V 10/5A
3/3A 50/25W
45/45W
Single (1.4”)
RFP-C1LAN-000-xxxx
Controller
module
- - - Single (1.4”)
