792 Configuration
life of the sensor has expired will be saved automatically with the
determination.
Stop determination
The running determination will be terminated automatically. The following
message must be confirmed with
[OK] .
Calibration data
Note
This tab only appears for pH and ISE electrodes.
Slope
pH electrode: -999.9 ... 999.9 %, [ 100.0 ]
ISE electrode: -999.9 ... 999.9 mV, [ 59.2/valency ]
Slope of the pH or ISE electrode. This value can be determined automati-
cally with a calibration from the linearized calibration curve or entered
manually. The slope of a sensor that is used by the commands
DET , MET ,
SET , KFT , MEAS and CAL LOOP is available as a variable 'Command name.SLO'
for calculations.
pH(0)
-20.000 ... [ 7.000 ] ... 20.000
The electrode zero point pH(0) is only shown for pH electrodes. After the
slope the pH(0) is the second characteristic quantity of the calibration func-
tion U = f(pH). pH(0) is the x-axis intercept of the calibration curve, i.e. it
corresponds to the pH value at 0 mV. The electrode zero point pH(0) of a
pH electrode that is used by the commands DET , MET , SET , KFT , MEAS and
CAL LOOP is available as a variable 'Command name.ENP' for calculations.
E(0)
-2000.0 ... [ 0.0 ] ... 2000.0 mV
The electrode zero point E(0) is only shown for ISE electrodes. E(0) is the
second characteristic quantity of the calibration function U = f(log c). E(0)
is the y-axis intercept of the calibration curve and corresponds to the poten-
tial at log c = 0. The electrode zero point E(0) of an ISE electrode that is
used by the commands DET , MET , SET , KFT , MEAS and CAL LOOP is available
as a variable 'Command name.ENP' for calculations.
