Commands 533
mol/L, mmol/L, µmol/L, [ ppm ], g/L, mg/L, µg/L, mg/mL, µg/mL, %, mEq/L
Concentration unit of addition solution.
Control parameters
Dosing rate
slow, medium, [ fast ]
Speed at which the volume increments are to be added.
Delta U
1 ... [ 10 ] ... 999 mV
Potential difference that is to be achieved by a standard addition.
Measuring parameters
Screenshot and parameters: see STDADD man - Measuring parameters
5.6.7 Calibration commands
Commands for calibration of pH- and ion selective sensors.
General
The commands CAL LOOP and CAL MEAS are available for calibrating electrodes.
The number and type of buffers or standards respectively is defined in the loop
command
CAL LOOP whereas the measurement is done with the command CAL
MEAS . The validity of the measurement is checked after each pass of the loop. The
calibration data for the electrode are determined at the end.
The basic structure of a calibration method looks as follows:
