Subwindow Run 139
Barcode reader
Device name
Selection of the barcode reader from which data is to be imported.
Always accept data
[ on ], off
If this option is selected then the data transmitted from the barcode reader
will be imported into the working sample table for which this barcode reader
has been defined as the data source.
Accept data only for active window
on, [ off ]
If this option is selected then the data transmitted from the barcode reader
will only be imported into the working sample table of the workplace which
has the focus.
Import from file
on, [ off ]
If this option is selected then external data will be imported from a file (e.g.
via LIMS) into the working sample table. A check will be made that the gi-
ven import file exists when loading a saved sample table into the working
sample table as well as at regular intervals (every 10 s) when the sample
table is open (but not when the dialog window
Edit line is open). If the im-
port file is present then the data from this file will be inserted automatically
at the end of the working sample table. The import file is deleted after each
import.
Note
Irresp. of the number of data fields defined on the tab
Display , all sample data in
the format Method name;Sample position;ID1;ID2;ID3;ID4;ID5;ID6;ID7;ID8; Sam-
ple size;Sample size unit have to be defined in the import file for each line.
Import file
File name
Entry or selection the file from which the import is to take place.
Import format
[ *.csv ]
Selection of the import format for the import of data from a file (only *.csv
possible).
Comment
Entry of a comment about the working sample table.
Comment on sample table
1000 characters
Entry of a comment about the working sample table.
