Actuator
series
Type
Feed
screw
Motor
output [W]
Encoder
resolution
Lead
[mm]
Mounting
direction
Maximum stroke
[mm]
Maximum
acceleration/
deceleration [G]
Minimum
push force
[N]
Maximum
push force
[N]
Rated push
speed
[mm/s]
Horizontal 465 0.3 - - -
10
Vertical 400 0.2 - - -
Horizontal 0.3 - - -
5
Vertical
250
0.2 - - -
Horizontal 0.2 - - -
TA5C
Ball
screw
20 800
2.5
Vertical
125
0.2 - - -
Horizontal 465 0.3 - - -
10
Vertical 400 0.2 - - -
Horizontal 0.3 - - -
5
Vertical
250
0.2 - - -
Horizontal 0.2 - - -
TA5R
Ball
screw
20 800
2.5
Vertical
125
0.2 - - -
Horizontal 560 0.3 - - -
12
Vertical 500 0.2 - - -
Horizontal 0.3 - - -
6
Vertical
300
0.2 - - -
Horizontal 0.2 - - -
TA6C
Ball
screw
20 800
3
Vertical
150
0.2 - - -
Horizontal 560 0.3 - - -
12
Vertical 500 0.2 - - -
Horizontal 0.3 - - -
6
Vertical
300
0.2 - - -
Horizontal 0.2 - - -
TA6R
Ball
screw
20 800
3
Vertical
150
0.2 - - -
Horizontal 600 0.3 - - -
12
Vertical 580 0.2 - - -
Horizontal 0.3 - - -
6
Vertical
300
0.2 - - -
Horizontal 0.2 - - -
TA7C
Ball
screw
30 800
3
Vertical
150
0.2 - - -
Horizontal 600 0.3 - - -
12
Vertical 580 0.2 - - -
Horizontal 0.3 - - -
6
Vertical
300
0.2 - - -
Horizontal 0.2 - - -
RCA2
(table
type)
TA7R
Ball
screw
30 800
3
Vertical
150
0.2 - - -
