Part 2 Startup Chapter
Chapter 5 Network Setup
308
Part 2 Startup Chapter
PLC
ROBONET
Refer to a separately
provided operation
manual for your PLC
when connecting the
PLC to a PC.
[For connection of a PLC with
ROBONET, refer to 2.2.8.]
Connecting a PC with an USB:
CB-SEL-USB030, RCB-CV-USB and CB-RCA-SI0050
Connecting a PC with RS485:
RCB-CV-MW and CB-RCA-SI0050
5.2.2 DeviceNet
Slave addresses are assigned using DeviceNet Configurator (addresses can be assigned freely).
This configurator by Omron comes preinstalled with the EDS files for Omron’s DeviceNet products. However, the EDS file for
ROBONET is not preinstalled and must be installed separately. Download the EDS file for ROBONET (robonet_2_1.eds) from
our website at the following address:
Website: http://www.intelligentactuator.com
In this section, the network configuration procedure using CX-Integrator based on free assignment is explained (using the
following system configuration as an example).
