Part 1 Specification
Chapter 4 Controller Unit
191
Part 1 Specification
4.3 Name/Function of Each Part and External Dimensions.
The name/function of each part and external dimensions are exactly the same with both the RACON and RPCON. However,
the connector is different between the RACON and RPCON.
4.3.1 Name of Each Part
Axis address setting switch
Brake release switch
LED indicators
(Front cover open)
User setting switches
ROBONET communication
connectors
Power-supply terminal block
Simple absolute connector
Motor cable connector
Encoder cable connector
