Appendix D Register Index
D
D.2 REGISTER SYMBOL INDEX
A
ADCR:
A/D conversion result register ... 227
ADM:
A/D converter mode register ... 229, 304
ASIM:
Asynchronous serial interface mode register ... 245
ASIS:
Asynchronous serial interface status register ... 246
B
BRGC:
Baud rate generator control register ... 251
C
CR00:
16-bit compare register ... 111
CR01:
16-bit compare register ... 111
CR02:
16-bit capture register ... 111
CR10:
8-bit compare register ... 142
CR11:
8-bit capture/compare register ... 142
CR20:
8-bit compare register ... 161
CR21:
8-bit compare register ... 161
CR22:
8-bit capture register ... 161
CR30:
8-bit compare register ... 206
CRC0:
Capture/compare control register 0 ... 112
CRC1:
Capture/compare control register 1 ... 144
CRC2:
Capture/compare control register 2 ... 165
CSIM:
Clock synchronous serial interface mode register ... 262, 273
I
IF0:
Interrupt request flag register ... 305
INTM0: External interrupt mode register 0 ... 294
INTM1: External interrupt mode register 1 ... 295, 303
ISM0:
Interrupt service mode register ... 306
IST:
Interrupt status register ... 307
M
MK0:
Interrupt mask register ... 306
MM:
Memory expansion mode register ... 346
P
P0:
Port 0 ... 60
P2:
Port 2 ... 63
P3:
Port 3 ... 66
P4:
Port 4 ... 75
P5:
Port 5 ... 80
P6:
Port 6 ... 84
P7:
Port 7 ... 92
P0H:
Port 0 buffer register ... 97
P0L:
Port 0 buffer register ... 97
