APPENDIX D REGISTER INDEX
D.1 REGISTER INDEX
16-bit capture register (CR02) ... 111
16-bit compare register (CR00,CR01) ... 111
16-bit timer 0 (TM0) ... 111
8-bit capture/compare register (CR11) ... 142
8-bit capture register (CR22) ... 161
8-bit compare register (CR10) ... 142
8-bit compare register (CR20) ... 161
8-bit compare register (CR21) ... 161
8-bit compare register (CR30) ... 206
8-bit timer 1 (TM1) ... 142
8-bit timer 2 (TM2) ... 161
8-bit timer 3 (TM3) ... 206
A
A/D conversion result register (ADCR) ... 227
A/D converter mode register (ADM) ... 229, 304
Asynchronous serial interface mode register (ASIM) ... 245
Asynchronous serial interface status register (ASIS) ... 246
B
Baud rate generator control register (BRGC) ... 251
C
Capture/compare control register 0 (CRC0) ... 112
Capture/compare control register 1 (CRC1) ... 144
Capture/compare control register 2 (CRC2) ... 165
Clock synchronous serial interface mode register (CSIM) ... 262, 273
E
External interrupt mode register 0 (INTM0) ... 294
External interrupt mode register 1 (INTM1) ... 295, 303
I
Interrupt mask register (MK0) ... 306
Interrupt request flag register (IF0) ... 305
Interrupt service mode register (ISM0) ... 306
Interrupt status register (IST) ... 307
M
Macro service mode register ... 323
Memory expansion mode register (MM) ... 346
P
Port 0 (P0) ... 60
Port 2 (P2) ... 63
