438
µ
PD78214 Sub-Series
B.3 UPGRADING OTHER IN-CIRCUIT EMULATORS TO 78K/II SERIES LEVEL
The 78K series and 75X series in-circuit emulators can be upgraded to the level of the 78K/II series by replacing
their internal boards with an optional board.
Note that the upgraded in-circuit emulator requires an appropriate new control program.
B.3.1 Upgrading to IE-78240-R-A Level
IE-78230-R-A
IE-78140-R
IE-78240-R Note 1
IE-78112-R Note 1
IE-78210-R Note 1
IE-78220-R Note 1
IE-78310-R Note 1
IE-78310A-R
IE-75000-R
IE-75001-R
IE-78000-R
IE-78130-R
IE-78230-R
IE-78320-R Note 1
IE-78327-R
IE-78330-R
IE-78350-R
IE-78600-R Note 1
Emulator IE Group Number Required Board
—
The high-speed download function is
not supported. Those users who are
also using an in-circuit emulator of IE
group 1, 2, or 4, are recommended to
upgrade these emulators also. Those
users with an in-circuit emulator of IE
group 1 do not need to purchase the IE-
78200-R-BK (the IE-78200-R-BK board is
built into the IE group 1 in-circuit
emulator).
Those users with an in-circuit emulator
of IE group 1 do not need to purchase
the IE-78200-R-BK (the IE-78200-R-BK
board is built into the IE group 1 in-
circuit emulator).
Remarks
IE-78200-R-BK
IE-78240-R-EM
2
1 —
IE-78200-R-BK
IE-78240-R-EM
4
IE-78200-R-BK
IE-78240-R-EM Note 2
3
Notes 1. This product is no longer produced, and is not available from NEC.
2. This board is used for emulation for the µPD78214 series. Those users who already have the IE-78210-R-EM Note 1
do not have to purchase this board.
