NEC PD78214 User Manual
Page 441
412
µ
PD78214 Sub-Series
XOR1
SET1
CLR1
NOT1
Operation
Mnemonic
Operand
No. of
bytes
Flags
Z
AC
CY
CY, saddr.bit
3
CY
← CY ∨ (saddr.bit)
×
CY, sfr.bit
3
CY
← CY ∨ sfr.bit
×
CY, A.bit
2
CY
← CY ∨ A.bit
×
CY, X.bit
2
CY
← CY ∨ X.bit
×
CY, PSW.bit
2
CY
← CY ∨ PSW.bit
×
saddr.bit
2
(saddr.bit)
← 1
sfr.bit
3
sfr.bit
← 1
A.bit
2
A.bit
← 1
X.bit
2
X.bit
← 1
PSW.bit
2
PSW.bit
← 1
Ч
Ч
Ч
CY
1
CY
← 1
1
saddr.bit
2
(saddr.bit)
← 0
sfr.bit
3
sfr.bit
← 0
A.bit
2
A.bit
← 0
X.bit
2
X.bit
← 0
PSW.bit
2
PSW.bit
← 0
Ч
Ч
Ч
CY
1
CY
← 0
0
saddr.bit
3
(saddr.bit)
← (saddr.bit)
sfr.bit
3
sfr.bit
← sfr.bit
A.bit
2
A.bit
← A.bit
X.bit
2
X.bit
← X.bit
PSW.bit
2
PSW.bit
← PSW.bit
Ч
Ч
Ч
CY
1
CY
← CY
Ч
