431
Appendix B Development Tools
B
IE-78240-R-A The IE-78240-R-A is an enhanced version of the IE-78210-R and IE-78240-R.
This in-circuit emulator can be used for any model of the µPD78214 sub-series.
It operates with a PC-9800 series or IBM PC/AT host machine. By using this
emulator together with the optional screen debugger and device file, programs
written in C or a structured assembly language can be debugged at the source
program level. Features such as the simultaneous tracing of data access and
program fetch, as well as C0 coverage, enable efficient debugging and program
testing. For those already using the IE-78210-R or IE-78240-R, the emulator can
be upgraded to a level equivalent to the IE-78240-R-A simply by adding an
optional board (IE-78200-R-BK).
These in-circuit emulators can be used for any model of the µPD78214 sub-
series Note 1 . They are connected to a host machine or a console to enable
debugging. When connected to a host machine, they enable symbolic debug-
ging and allow object files to be exchanged with the host machine, thus
making the debugging process more efficient. These emulators each have two
RS-232C ports, to which the PC-1500 PROM programmer can be connected.
These boards are used to upgrade the 75X and 78K series in-circuit emulators
to a level equivalent to the IE-78240-R-A, IE-78240-R, or IE-78210-R Note 2 . For
details, see B.3.
These emulation probes are used for the µPD78210CW, µPD78212CW-×××,
µPD78213CW, µPD78214CW-×××, µPD78P214CW, µPD78212CW(A)-×××,
µPD78213CW(A), and µPD78214CW(A)-×××. The EP-78240CW-R is essentially
the same as the EP-78210CW, the only difference being that the former has a
longer cable.
These emulation probes are used for the µPD78212GC-×××-AB8, µPD78213GC-
AB8, µPD78214GC-×××-AB8, µPD78P214GC-AB8, µPD78212GC(A)-×××-AB8, and
µPD78214GC(A)-×××-AB8. Both are used together with the EV-9200GC-64. The
EP-78240GC-R is essentially the same product as the EP-78210GC, the only
difference being that the former has a longer cable.
This emulation probe is used for the µPD78210GJ-5BJ, µPD78212GJ-×××-5BJ,
µPD78213GJ-5BJ, µPD78214GJ-×××-5BJ, µPD78P214GJ-5BJ, and
µPD78214GJ(A)-×××-5BJ. It is used together with the EV-9200G-74 and EP-
78210L or EP-78240LP-R.
This emulation probe is used for the µPD78210GJ-5BJ, µPD78212GJ-×××-5BJ,
µPD78213GJ-5BJ, µPD78214GJ-×××-5BJ, µPD78P214GJ-5BJ, and
µPD78214GJ(A)-×××-5BJ. It is used together with the EV-9200G-74. Unlike the
EP-78210GJ, this probe is of single-unit type, and is thus easier to use.
These emulation probes are used for the µPD78213GQ-36, µPD78214GQ-×××-36,
µPD78P214GQ-36, µPD78213GQ(A)-36, and µPD78214GQ(A)-×××-36. The EP-
78240GQ-R is essentially the same product as the EP-78210GQ, the only
difference being that the former has a longer cable.
These emulation probes are used for the µPD78210L, µPD78213L, µPD78214L-
×××, µPD78P214L, and µPD78214L(A)-×××. The EP-78240LP-R is essentially the
same product as the EP-78210L, the only diffence being that the former has a
longer cable.
B.1 HARDWARE (1/2)
IE-78240-R Note 2
IE-78210-R Note 2
IE-78240-R-EM
IE-78210-R-EM Note 2
IE-78200-R-EM Note 2
IE-78200-R-BK
EP-78240CW-R
EP-78210CW Note 2
EP-78240LP-R
EP-78210L Note 2
EP-78240GJ-R
EP-78240GQ-R
EP-78210GQ Note 2
EP-78240GC-R
EP-78210GC Note 2
EP-78210GJ Note 2
Notes 1. µPD78212, µPD78213, µPD78214, µPD78P214, µPD78212(A), µPD78213(A), and µPD78214(A)
2. These products are no longer produced and are not available from NEC.
