Page 464: B.2.2 software for the in-circuit emulator (1/2)
435
Appendix B Development Tools
B
OS
µS5A10CC78K2-L
µS5A13CC78K2-L
µS7B10CC78K2-L
µS7B13CC78K2-L
µS3H15CC78K2-L
µS3K15CC78K2-L
µS3M15CC78K2-L
Part number
5.25-inch 2HD
3.5-inch 2HD
5.25-inch 2HC
3.5-inch 2HC
Distribution medium
Host machine
This source program is used to modify the libraries supplied with CC78K/II to
satisfy user specifications.
78K/II series C compiler
library source file
HP-UX (rel.7.05B)
Sun OS (rel.4.1.1)
EWS-UX/V (rel.4.0)
HP9000 series300
SPARCstation
EWS-4800 series (RISC)
Cartridge tape
(QIC-24)
See Section B.2.4.
MS-DOS (Ver.3.30 to
Ver.5.00A
Note
)
PC-9800 series
IBM PC/AT or
compatible
Language Processing Software (3/3)
Note
Versions 5.00 and 5.00A feature a task swap function. However, the task swap function cannot be used with this
software.
B.2.2 Software for the In-Circuit Emulator (1/2)
★
★
This program controls the in-circuit emulator for the 78K/II series when used
together with the device file (DF78210). It can be used when the in-circuit emulator
has been upgraded to IE-78240-R-A class and a PC-9800 series or IBM PC/AT
computer is being used as a host computer. This debugger can debug source
programs written in C, structured assembly language, and assembly language. Its
split screen function, by which the screen is split into sections to enable the
simultaneous display of different information, makes debugging more efficient.
Screen debugger
(SD78K/II)
OS
µS5A10SD78K2
µS5A13SD78K2
µS7B10SD78K2
µS7B13SD78K2
Part number
5.25-inch 2HD
3.5-inch 2HD
5.25-inch 2HC
3.5-inch 2HC
Distribution medium
Host machine
See Section B.2.4.
This is used together with the screen debugger (SD78K/II) to debug programs of
the
µPD78214 sub-series.
Device file (DF78210)
OS
µS5A10DF78210
µS5A13DF78210
µS7B10DF78210
µS7B13DF78210
Part number
5.25-inch 2HD
3.5-inch 2HD
5.25-inch 2HC
3.5-inch 2HC
Distribution medium
Host machine
See Section B.2.4.
MS-DOS (Ver.3.30 to
Ver.5.00A
Note
)
MS-DOS (Ver.3.30 to
Ver.5.00A
Note
)
PC-9800 series
PC-9800 series
★
★
Note
Versions 5.00 and 5.00A feature a task swap function. However, the task swap function cannot be used with this
software.
IBM PC/AT or
compatible
IBM PC/AT or
compatible
