Fig. 13-16 Write Timing of Programmable Wait Function (2/2)
(c) When two wait states are set
Higher address
Lower
address
Data
Hi-Z
Hi-Z
A8-A15
(output)
AD0-AD7
(output)
ASTB (output)
WR (output)
Hi-Z
f
CLK
Note
Note f
CLK
: System clock frequency (f
XX
/2)
