Chapter 18 Instruction Operations
18
Z
:
Zero flag
RBS1-RBS0 :
Register bank selection flag
IE
:
Interrupt request enable flag
STBC
:
Standby control register
jdisp8
:
Signed 8-bit data (displacement: –128 to +127)
( )
:
Contents at address enclosed in parentheses or at address indicated in register enclosed in
parentheses
××H
:
Hexadecimal number
×
H
,
×
L
:
Eight high-order bits and eight low-order bits of 16-bit register pair
18.1.3 Flag Field
Blank
:
No change
0
:
Cleared to zero.
1
:
Set to 1.
×
:
Set or cleared according to the result.
R
:
Saved values are restored.
