Parameters
interface
Enter one of the following interface types:
• 10 Gigabit Ethernet: tengigabitethernet {slot/
port |slot/port-range}
• Port channel: port-channel {1-512 | port-
channel-range}
Where port-range and port-channel-range specify a
range of ports separated by a dash (-) and/or individual
ports/port channels in any order; for example:
tengigabitethernet 1/1-2,5,9,11-12 port-
channel 1-3,5. A comma is required to separate each port
and port-range entry.
Defaults
none
Command
Modes
UPLINK-STATE-GROUP
Command
History
Version 9.4(0.0)
Supported on the FN I/O aggregator. This command is
supported in Programmable-Mux (PMUX) mode only.
Usage
Information
You can assign physical port or port-channel interfaces to an uplink-state group.
You can assign an interface to only one uplink-state group. Configure each
interface assigned to an uplink-state group as either an upstream or downstream
interface, but not both.
You can assign individual member ports of a port channel to the group. An uplink-
state group can contain either the member ports of a port channel or the port
channel itself, but not both.
Related
Commands
•
— assigns a port or port-channel to the uplink-state group as an
upstream interface.
•
— creates an uplink-state group and enables the tracking of
upstream links.
downstream auto-recover
Enable auto-recovery so that UFD-disabled downstream ports in an uplink-state group automatically
come up when a disabled upstream port in the group comes back up.
Syntax
downstream auto-recover
To disable auto-recovery on downstream links, use the no downstream auto-
recover command.
Defaults
The auto-recovery of UFD-disabled downstream ports is enabled.
449
