• Forced-master
• Force-slave
• Master
• Slave
• Auto-neg Error — typically indicates that both ends of the node are configured
with forced-master or forced-slave.
CAUTION: Ensure that one end of your node is configured as forced-master
and one is configured as forced-slave. If both are configured the same (that
is, forced-master or forced-slave), the show interfaces command flaps
between an auto-neg-error and forced-master/slave states.
You can display master/slave settings with the show interfaces command.
Example
(Master/Slave)
Dell(conf)# int tengig 0/1
Dell(conf-if)#neg auto
Dell(conf-if-autoneg)# ?
end Exit from configuration mode
exit Exit from autoneg configuration mode
mode Specify autoneg mode
no Negate a command or set its defaults
show Show autoneg configuration information
Dell(conf-if-autoneg)#mode ?
forced-master Force port to master mode
forced-slave Force port to slave mode
Dell(conf-if-autoneg)#
Example
(Master/Slave,
partial)
Dell#show interfaces configured
TenGigabitEthernet 0/1 is up, line protocol is up
Hardware is DellEth, address is 00:1e:c9:de:04:9c
Current address is 00:1e:c9:de:04:9c
Server Port AdminState is N/A
Pluggable media not present
Interface index is 33886978
Internet address is not set
Mode of IPv4 Address Assignment : NONE
DHCP Client-ID :001ec9de049c
MTU 12000 bytes, IP MTU 11982 bytes
LineSpeed 10000 Mbit
Flowcontrol rx on tx off
ARP type: ARPA, ARP Timeout 04:00:00
Last clearing of "show interface" counters 03:56:48
Queueing strategy: fifo
Input Statistics:
...
User
Information
Both sides of the link must have auto-negotiation enabled or disabled for the link
to come up.
The following details the possible speed and auto-negotiation combinations for a
line between two 10/100/1000 Base-T Ethernet interfaces.
Port 0
• auto-negotiation enabled* speed 1000 or auto
