MTS MultiPurpose TestWare®
MPT Options Editor Unit Selection Tab
MPT Options Editor 82
For more information See “About Default Templates” on page 553.
Use Station Unit
Assignment Set Note By default, this control is enabled in the default template. To disable
this control for new procedures, you must disable it in the default
template.
When enabled for existing procedures: Causes the procedure to acquire the
current default UAS selection. If this box was disabled when you opened a
procedure and you enable it while editing the procedure, you will see the units
in your procedure change from the UAS assigned when you opened the
procedure to the UAS set in the registry. The new UAS assignment are not
permanent until you save the procedure. If you close without saving, the UAS
assignment reverts to the set assigned when you opened the procedure.
When enabled for new procedures: Causes new procedures to open with the
UAS selection set in the registry.
When disabled for existing procedures: With this control, you can select and
edit any UAS and assign it to the current procedure. When you save your
procedure, your specific UAS selection is saved with your procedure. If
keeping a specific UAS assignment linked to your procedure is important to
you, this is a good choice.
When disabled for new procedures: Causes new procedures to open with the
UAS selection set in the registry. If you want all new procedures to open with a
specific UAS that is independent of the station configuration UAS, change the
UAS selection in the default template.
Edit... Opens the Unit Assignment Set Editor. Using this editor, you can create new or
edit existing unit assignment sets.
Unit Selection Tab (part 2 of 2)
I TEM D ESCRIPTION
