The MultiPurpose TestWare Interface
MTS MultiPurpose TestWare® About MultiPurpose TestWare 27
For more information See “MPT Specimen Editor” on page 131.
See “About the MPT Procedure Editor” on page 36.
See “Edit mode” on page 27.
Edit mode
Execute mode
Changes between edit and execute test modes. To change (toggle between)
modes, click the edit /execute mode button.
You must be in edit mode to create or make changes to your procedure.
Note You cannot switch to edit mode if the procedure is running or holding.
You must be in the execute mode to run your test. The procedure automatically
switches to execute mode if you click run on the Station Controls panel.
Note When you change to execute mode, the MPT application becomes the
controlling application of the control channels used in the procedure.
You cannot use the Station Managermanual command controls on
the control channels used in the procedure.
Quits the MultiPurpose TestWare application.
MPT Control Panel Toolbar (part 2 of 2)
I TEM D ESCRIPTION
