Profile with ALC Process
MTS MultiPurpose TestWare® Command Processes 237
Matrix tab
Note This tab is enabled only if ALC has been selected as the Adaptive
Compensator on the Command tab.
Matrix Tab (part 1 of 2)
I TEM D ESCRIPTION
Compensation Matrix
Name Names the matrix used by the ALC compensator.
ALC matrix files are saved in the Specimen directory. The default ALC matrix
file is default.mat. If you want to use an existing matrix, copy the mat file into
the Specimen directory, and then type the matrix file name in the
Compensation Matrix Name box.
Initial Gain Specifies the amount of initial gain applied to the signal. The default is 100%,
or no magnification.
Enable Frequency
Compensation Attempts to run the test at a faster rate than specified in the selected profile.
For example, if the profile specifies that the end levels be achieved using a
frequency of 0.2 Hz, the application may actually achieve these end levels at
0.5 Hz. The maximum rate increase is specified on the ALC tab in the
Compensators tab in the Station Setup window in Station Manager.
Note This option is available only if you have specified a single-channel
profile.
