MTS Series 793 Application - Manual (Page 542)

MTS MultiPurpose TestWare®
Profile Editor Controls and Displays
Model 793.11 Profile Editor 542
Channel Menu
With the Channel menu you can add and remove channels from the profile. You
can also select which channel will “have focus.”
Tools Menu
Use the Tools menu commands to:
• Display a Graphical Preview for the x-y plot of the current profile.
• Choose preferences for viewing profile plots and selecting directories.
• Analyze the current profile for possible design errors.
For more information
For more information see “Analyze Window” on page 548.
Channel Menu
I TEM D ESCRIPTION
Add Adds a channel to the profile.
Remove Deletes a channel from the profile.
Note The master channel of a phase file cannot be removed.
Show Brings focus to one of the channel windows (making it the “active” window).
Tools Menu
I TEM D ESCRIPTION
Show Graph Displays the Graphical Preview window.
Options Editor Displays the Options Editor window.
Analyze Checks the profile for potential design errors. If the application detects an
error, it displays a message detailing problems, that you should be aware of
before you save the profile. All the errors must be resolved before you can save
the profile.
