MTS Series 793 Application - Manual (Page 348)

MTS MultiPurpose TestWare®
Data Limit Detector Process
Event Process Descriptions 348
Data Limit Detector Parameter Descriptions
Limits tab
Signals tab
Selects the signals that this process monitors. Use the left and right arrows to
move desired signals to the Included list.
Settings tab
Limits Tab
I TEM D ESCRIPTION
Signal Displays the signals that may be monitored for limit detection. Only signals
moved to the Included column on the Signals tab appear in this list.
Upper/Lower Limit Enables the upper and lower limit controls, which allow you to specify
associated limit detector values.
Note If you want to temporarily disable a defined limit (for example, for a test
run), uncheck the associated checkbox.
Settings Tab (part 1 of 3)
I TEM D ESCRIPTION
Limit Mode Specifies whether the process limit values are absolute or relative to the signal
value at the start of the process.
Process completes
when Select Any selected signal exceeds its limit to end the process when any
signal exceeds its limit.
Select All selected signals exceed their limits to end the process once all
signals have exceeded their limits at some time during the process.
