Dwell Command Process
MTS MultiPurpose TestWare® Command Processes 195
Dwell Command Process
About the Dwell Command Process
The Dwell Command process is a single segment designed to hold your
command at a static level for a specified amount of time.
When you define a Dwell Command process you must specify the duration of
the command as a time or a frequency:
• Time specifies the amount of time to run the single dwell command
segment.
• Frequency specifies the frequency of a command cycle (two-segments).
Since a dwell command is a single segment, the actual dwell command hold
time is half of the frequency setting. (For example, a frequency setting of 2
Hz holds the command for 0.25 seconds.)
Dwell Command Parameter Descriptions
Command tab
Command Tab
I TEM D ESCRIPTION
Time/Frequency Specifies how fast the segment runs. Options are:
• Time—specifies the time to run one segment.
• Frequency—specifies the time to run a two-segment cycle.
Do Not Update
Counters Disables the counters. When enabled, the Channel Counters do not increment
for this process and the counter totals are unaffected.
Channel Specifies the channel.
Control Mode Specifies the control mode or control-mode variable.
