Data Display Process
MTS MultiPurpose TestWare® Other Process Descriptions 443
Signals of
Dimension/
Included on
Plot Displays signals on the plot with unit dimensions matching the current List
Filter selection.
Use the > to move individual signals, or the >> to move all signals, from the
Signals of Dimension list to the Included on Plot list as desired.
Note Only signals with the same dimension can be plotted on the same
axis.
Signal Displays the signals that were added to the Included on Plot list.
Note This control, and those listed below it, are not displayed until you move
a signal to the Included on Plot list.
Show Values Shows or hides the selected signal values in a table below the plot (in the plot
window).
Units Specifies the units for the Y1 or Y2 axis.
Initial
Minimum/
Maximum Sets the Y1 or Y2 axis initial maximum and minimum values. The plot will
autoscale if necessary.
Plot Setup Tab (part 2 of 7)
I TEM D ESCRIPTION
