MTS Series 793 Application - Manual (Page 304)

MTS MultiPurpose TestWare®
High Speed Timed Acquisition Process
Data Acquisition Process Descriptions 304
• 2048 System Rate:
• 1024 System Rate:
M AXIMUM S AMPLE RATE M AXIMUM N UMBER OF S IGNALS
3072 59
6144 29
12288 14
15360 11
24576 7
30720 5
M AXIMUM S AMPLE RATE M AXIMUM N UMBER OF S IGNALS
2048 89
4096 44
6144 29
8192 22
10240 17
12288 14
15360 11
20480 8
24576 7
30720 5
