High Speed Timed Acquisition Process
Data Acquisition Process Descriptions 308
Note Discard Data options are not available for the High Speed Acquisition
process.
Note The default buffer size is 16384, the range is from 1024 - 16384.
General tab
For more information
See “About Buffers” on page 272.
See “About Station Signals” on page 276.
For a table showing the maximum sample rates for various hardware, number of
signals, and system rates, see
“About the Timed Acquisition Process” on page
284.
How to Define a High Speed Timed Acquisition Process
1. Drag the icon from the Process Palette to your procedure table.
2. Click the process icon in the procedure table or navigation pane.
3. In the parameters window, click the Acquisition tab.
4. In the Time Between Points box, set the units of measurement and type a
value. Or, select Sample Rate, and specify the rate at which the system will
acquire data.
General Tab
I TEM D ESCRIPTION
Name Specifies the process name displayed on the Procedure or Group process
window.
Process Enabled Enables the process. (Clear this box to disable the process.)
Execute Process Specifies the number of times the process will be run.
Counter Type Enables a process counter.
Options are None, Transient, or Fixed. Transient counters are displayed only
when the process is active. Fixed counters are displayed throughout the test.
Counter Label Names the counter.
When you run the test, this name appears under Sequence Counters on the
MPT control panel.
Note If this box is blank, the process name is used as the counter label.
