MTS MultiPurpose TestWare®
Data Display Process
Other Process Descriptions 444
Options Subtab Lets you define visual characteristics of the plot and buffer size, and choose
which data is displayed.
Show Grid Hides or displays the grid in the plot window.
Show Legend Hides or displays the legend in the plot window.
Transpose X/Y
Axis Transposes the X and Y1 axes.
Note This option is disabled if both the Y1 and Y2 axes are used.
Buffer Size Sets the size of the display buffer, which ranges between 4096 and 16,384.
Note When the buffer is filled, room for new data in the buffer is based on
the Decimation Option (data is deleted according to the current
Decimation Option).
Plot Setup Tab (part 3 of 7)
I TEM D ESCRIPTION
