The MultiPurpose TestWare Interface
About MultiPurpose TestWare 28
MPT Test Progress Panel
The Test Progress panel displays the elapsed run time of the test that is in
progress and indicates if the test is currently paused.
For more information
See “MPT Options Editor Control Panel Tab” on page 79.
For more information about pausing a test with the Program Control process, see
“About the Program Control Process” on page 400.
MPT Test Progress Panel
I TEM D ESCRIPTION
Run Time Displays the elapsed time of the current test (the elapsed run time does not
include time spent in hold or stop states).
You can turn the Run Time display on-and-off and select a display format
using the Control Panel tab of the MPT Options Editor.
To access the Run Time menu when the procedure is locked and reset, right-
mouse click with the cursor positioned over the Run Time counter to display.
Select the Reset menu item to reset the Run Time counter to zero.
Paused Indicates when the procedure has been paused by a Program Control process.
The paused state is not the same as the hold state.
• When the test is holding, you must click the run button to resume the test.
• When the test is paused, the test must be resumed by another Program
Control process (set to Program Resume).
