MTS MultiPurpose TestWare®
MPT Procedure Editor
About MultiPurpose TestWare 38
Tools Menu
Use the Tools menu commands to display various editors used to customize the
MPT environment and/or the current procedure.
MPT Procedure Editor Toolbar
The buttons that comprise the MPT Procedure Editor toolbar provide quick
access to common commands and windows.
Tools Menu
I TEM D ESCRIPTION
Specimen Editor Displays the MPT Specimen Editor.
Unit Set Editor Displays the Unit Set Editor.
Options Editor Displays the Options Editor.
MPT Procedure Editor Toolbar (part 1 of 2)
I TEM D ESCRIPTION
Deletes the process (or processes) selected in the active procedure table.
Opens the next group table. This button is only active if there are multiple
group tables available.
Opens the previous group table. This button is only active if there are multiple
group tables available.
Displays the Process Palette. You can select processes from the palette to copy
to the MPT Procedure Editor, or you can drag and drop processes from the
palette to the MPT Procedure Editor.
Displays the MPT Options Editor. With the MPT Options Editor, you can
select control options and preferences for the current procedure.
Displays the MPT Variables Editor.
Displays the MPT Specimen Editor. You can use the MPT Specimen Editor to
create and edit multiple MPT specimens.
