MTS MultiPurpose TestWare®
Data Limit Detector Process
Event Process Descriptions 350
Limit table tab
The Limit Table tab displays all the limits defined in this process. You can edit
any data limit value in this window. To enable a limit, select the check box next
to the signal name. To disable a limit, clear the check box next to the signal name.
Action Specifies the action that occurs when the process completes.
None The process ends without generating a message or performing an action.
Station Power
Off The process removes hydraulic power from the station. The test can be
resumed after you reset interlocks and reapply hydraulic power to the station.
Interlock The process triggers a hydraulic interlock and shuts down the hydraulic power
supply. The test can be resumed after you reset the interlock, reactivate
hydraulic power.
Program
Interlock The process triggers a program interlock. The test can be resumed after you
reset the interlock.
Program Stop The process stops the test. This action functions the same as clicking the Stop
button on the Station Controls panel.
Program Hold The process suspends the test until you click the Run button on the MPT
control panel. This action functions the same as clicking the Hold button on
the Station Controls panel.
Settings Tab (part 3 of 3)
I TEM D ESCRIPTION
