High Speed Timed Acquisition Process
MTS MultiPurpose TestWare® Data Acquisition Process Descriptions 303
494 hardware sample
rates
The following sample rates apply to series 494 hardware (models 494.25, 494.26,
and 494.16):
1
• 6144 System Rate:
• 4096 System Rate:
• 3072 System Rate:
1. To make signals available, each Series 494 conditioner’s Analog Input HWI
Editor properties must have the High Speed Data setting set to True.
M AXIMUM S AMPLE RATE M AXIMUM N UMBER OF S IGNALS
6144 29
12288 14
24576 7
30720 5
61440 2
M AXIMUM S AMPLE RATE M AXIMUM N UMBER OF S IGNALS
4096 44
8192 22
12288 14
20480 8
24576 7
40960 4
61440 2
