Profile with ALC Process
MTS MultiPurpose TestWare® Command Processes 235
Mapping tab
Mapping Tab
I TEM D ESCRIPTION
Channel Displays all station control channels.
Profile Channel Selects the profile channel that will be played out on this station channel.
You must map the logical channels in your profile to the control channels in
your station configuration. You can arbitrarily map any profile channel to any
station channel, or you can map a single profile channel to multiple station
channels. If you leave any station channel unmapped, no profile will be played
out on that channel.
If you gave the profile channels the same name(s) as the station channels, they
will automatically be mapped to the station channel with the matching name. A
profile channel will appear in the Profile Channel list box next to its
corresponding (station) Channel.
Each Profile Channel list box will contain all the profile channels with units
that can be played out by any control mode for the station channel. For
example, a profile channel that measures length will not map to a station
channel with a temperature control mode.
If the profile was created with normalized dimensions then you can select any
of the control modes available to the station channel when defining the control
mode of the profile channel.
Control Mode Specifies the control mode for the selected station channel.
Level Reference Introduces a mean level offset to the selected station channel.
Level Multiplier Scales the end level values of the profile. The Level Multiplier will function
for both engineering units and “normalized units.”
Note For normalized units, the Profile Command process uses the Level
Multiplier value as the full scale.
