Model 793.12 Trend Monitoring Application
MTS MultiPurpose TestWare® Trend and Fatigue Monitoring Applications 459
Trend Monitoring Control Panel
With the Trend Monitoring Control Panel, you can choose which procedure for
which to display trend information. It also includes a toolbar with which you can
open trend data files and quit the Trend Monitoring application.
Trend Monitoring Control Panel
I TEM D ESCRIPTION
Displays the Open Trend Data File window:
You use this window to open an existing trend data file and display its
contents. If a data file has been opened before, the display will be updated to
show the new trend data.
Quits the Trend Monitoring application.
Note If data has already been received, a message will prompt you to
confirm the Exit command.
Active Procedures Specifies a procedure to display.
