Cyclic Acquisition Process
MTS MultiPurpose TestWare® Data Acquisition Process Descriptions 315
Note Buffer settings are not available for the Cyclic Data Acquisition process.
Output units tab
General tab
Buffer Type Specifies the buffer type.
Write First Data Header
Only Specifies if the data header is written for each buffer or suppressed after the
first header is written. If disabled (unchecked), a data header is written for each
buffer.
Note This feature is not recommended for procedures with multiple data
acquisition processes writing data to the same data file.
Destination Tab (part 2 of 2)
I TEM D ESCRIPTION
Output Units Tab
I TEM D ESCRIPTION
UAS Specifies the unit assignment set that will be applied to acquired data.
Select Other Displays other existing unit assignment sets from which you can choose a
UAS. This button is enabled only when you select the Other Unit Assignment
Set option.
Edit Opens the Unit Assignment Set Editor so you can modify a unit assignment
set.
General Tab
I TEM D ESCRIPTION
Name Specifies the process name displayed on the Procedure or Group process
window.
Process Enabled Enables the process. (Clear this box to disable the process.)
Execute Process Specifies the number of times the process will be run.
