Fatigue Process
MTS MultiPurpose TestWare® Data Acquisition Process Descriptions 325
Signals tab
Signals Tab
I TEM D ESCRIPTION
Signals Displays the signals which can monitored by the Fatigue process.
Units Displays the signal units.
Sensitivity Defines the Sensitivity for the peak/valley detector.
Note The units are the same as the full scale units.
Lower Range Specifies the lower boundary of the histogram.
Upper Range Specifies the upper boundary of the histogram.
Bin Size Specifies the distance between each histogram bin boundary for the selected
channel.
Note The units are the same as the full scale units.
Number of Bins Specifies the number of bins between the upper and lower range.
Material Assigns a material to the current signal.
Exp. Life Specifies a value for the specimen life expectancy (the number of tests the
specimen will survive before breaking).
Note If you do not know it, leave it at 1.0. This value is used by the Fatigue
Monitoring application to display the Percentage of Lifetime instead
of the damage.
