Set Process Parameters in the Procedure Table
MTS MultiPurpose TestWare® Creating a Practice Test Procedure 171
6. Define the Group (Fan Control) process.
A. In the MPT Procedure Editor, click the Group (Fan Control) process
icon.
B. Click the General tab. Instead of using the default settings, type and
select the parameters needed for the test, as follows:
• Name: Fan Control
• Process Enabled (enabled)
• Execute Process: 1000000 Times
• Counter Type: Fixed
• Counter Label: Cooling Cycles
Note By default, a Group process executes once. It completes when all of the
processes in the group are done. By typing a large number in the
Execute Process box, we are essentially instructing this Group process
to loop continuously.
For more information
For information on the parameter window controls, see “Segment Command
Parameter Descriptions” on page 182, “Cyclic Command Parameter
Descriptions” on page 191 “Peak/Valley Acquisition Parameter Descriptions” on
page 280, and “Digital Input Detector Parameter Descriptions” on page 354.
Group
(Fan Control)
