About Group Process Interrupts
MTS MultiPurpose TestWare® Working with MPT Processes 101
If neither the Cyclic or Segment processes have an interrupt selected, the
following things occur when the Group is interrupted:
• The Cyclic process ends immediately.
• The Segment process ends immediately.
• The Group process ends immediately.
User-defined interrupt
example
Suppose we start with the same scenario, but in this case, the Cyclic process’
interrupt is set to .Interrupt.
Segment
Normal Interrupt
to a Group
Process
When the Group
process is
interrupted, the the
Group ends
immediately.
Interrupt
Done Start
Group
Process
Trigger
Cyclic
