MTS MultiPurpose TestWare®
The MultiPurpose TestWare Interface
About MultiPurpose TestWare 32
MPT Channel Counters Panel
The Channel Counters panel displays the running total of completed command
channel cycles or segments during test execution.
For more information See “MPT Options Editor Control Panel Tab” on page 79.
MPT Channel Counters Panel
I TEM D ESCRIPTION
Channel Counters Displays a running total of the cycles or segments that have been run during
the test for each command channel specified in the procedure.
The Channel Counters panel displays all channels that are selected for use
during a test. A channel does not have to be used in every process to be
displayed.
You can specify the Channel Counters display format using the Control
Panel tab of the MPT Options Editor. You must be in edit mode to change the
Control Panel settings.
To access menu items that pertain to Channel Counters position the cursor
over the Channel Counters display and perform a right-mouse click. When
you do this, the Reset Counters and Set Counters... menu items appear
(provided that the procedure is locked and in the reset state). The Reset
Counters selection resets all active channel counters to zero. With the Set
Counters... selection you can manually set each channel counter to a user
specified value.
