High Speed Timed Acquisition Process
MTS MultiPurpose TestWare® Data Acquisition Process Descriptions 307
Note If the Time signal is selected, data is generated, not sampled. The Time
signal value always starts at zero.
Destination tab
Output Units tab
Destination Tab
I TEM D ESCRIPTION
Buffer Size Specifies the maximum number of data elements the buffer will store before data is
written to the disk.
Data Header Includes a label that describes the data on each buffer that is written to a file.
Destination Specifies where data is saved:
Specimen data file—the process writes buffers of data to the MPT specimen.dat
file in the Specimen.
User-specified data file—the process writes buffers of data to a separate data file
in the Specimen (yourname.dat).
Discard data—the process will not write data to the Specimen.
User Data File Specifies the name of the file where data is saved. This lets you create separate data
files in the MPT specimen. This control is enabled only when you have selected
User-specified data file in the Destination list above.
Buffer Type Specifies the buffer type.
Write First Data Header
Only Specifies if the data header is written for each buffer or suppressed after the first
header is written. If disabled (unchecked), a data header is written for each buffer.
Note This feature is not recommended for procedures with multiple data
acquisition processes writing data to the same data file.
Output Units Tab
I TEM D ESCRIPTION
UAS Specifies the unit assignment set that will be applied to acquired data.
Select Other Displays other existing unit assignment sets from which you can choose a UAS.
This button is enabled only when you select the Other Unit Assignment Set option.
Edit Opens the Unit Assignment Set Editor so you can modify a unit assignment set.
