MTS MultiPurpose TestWare®
High Speed Timed Acquisition Process
Data Acquisition Process Descriptions 302
Keep in mind that the actual sample duration (and number of points acquired) is
limited by the processor speed, the number of signals being sampled, the number
and type of other processes running concurrently, and so forth. If MPT cannot
store data as fast as it is acquired, an acquisition overrun will occur, and the test
will stop (data acquired up to that point will be saved).
Note If an acquisition overrun occurs, the test can be resumed without being
reset.
493 hardware sample
rates
The following sample rates apply to series 493 hardware (models 493.21B and
493.25):
• 6144 System Rate:
• 4096 System Rate:
M AXIMUM S AMPLE RATE M AXIMUM N UMBER OF S IGNALS
6144 23
12288 11
24576 5
49152 2
M AXIMUM S AMPLE RATE M AXIMUM N UMBER OF S IGNALS
4096 35
8192 17
12288 11
16384 8
24576 5
49152 2
