MTS MultiPurpose TestWare®
Set Controller Value Process
Other Process Descriptions 432
Set Controller Value Process Parameter Descriptions
Calc Parameters and
Calc Variables tabs
Values tab
Calc Parameters and Calc Variables Tabs
I TEM D ESCRIPTION
Available/Selected The Parameters page lists all the calculation parameters defined in the Station
Manager application.
The Variables page lists all the calculation variables defined in the Station
Manager application.
Use the arrow keys to move the desired items from the Available to the Selected
list. The items in the Selected list will appear on the Values page, where you can
set their values.
Values Tab
I TEM D ESCRIPTION
Calc. Parameter Lists all the calculation parameters and variables defined in the Station Manager
application and selected in the Parameters and Variables pages.
Set Value Allows you to enter the calculation parameter or variable value that will be used
in place of the associated value set in Station Manager. You can enter a new value
directly or assign an MPT variable.
